3 analog inputs (one
suitable as digital stereo AES/EBU input) and 6 analog
outputs for maximum flexibility
|
|
High-end AKM® 24-bit/96 kHz
A/D and D/A converters for ultimate signal integrity and
wide dynamic range (113 dB)
|
|
Integrated sample rate
converter for easy connection of external digital
signals with sampling rates from 32 to 96 kHz
|
|
Precise dynamic EQs for
level-dependent equalization and extremely musical
parametric EQs, selectable for all inputs and outputs
|
|
Several types of EQs (LP/BP/HP)
for each input and output
|
|
"Zero"-attack
limiters on all output channels for optimal speaker
protection
|
|
Four different mono and
stereo output operating modes
|
|
Individual crossover filter
types (Butterworth, Bessel and Linkwitz-Riley) with
selectable roll-off characteristics from 6 to 48 dB/octave
|
|
Adjustable delays for all
inputs and outputs-allow manual or automatic correction
for room temperature, phase and arrival time differences
|
|
Additional sum signal
derived from the A/B/C inputs offers a fourth internal
input signal
|
|
Future-proof ULTRADRIVE PRO
software enables single or multi remote control via PC
through RS-232 and RS-485 interfaces
|
|
Link option via RS-485
network interface enables cascading of several
ULTRADRIVE PROs
|
|
60 user-defined internal
presets storable via PC software or on PCMCIA card
|
|
Open architecture assures
easy software updates
|
|
Ultra low-noise 4580
operational amplifiers for outstanding audio performance
|
|
Servo-balanced, gold-plated
XLR connectors for all inputs and outputs
|
|
High-quality components and
exceptionally rugged construction for long life and
durability
|
|
Internal switch-mode power
supply for maximum flexibility (100 - 240 V~),
noise-free audio, superior transient response plus
lowest possible power consumption
|
|
Designed in Germany.
Manufactured under ISO9000 certified management system
|
