Tannoy |
Firstly
as a dedicated centre channel monitor in a Reveal 5.1 surround system. Its
low profile is necessary for many installations but it is critical to
maintain the same quality when panning across left, centre, right. The
Reveal X therefore uses the same drive units as Reveal to ensure
consistency of sound quality, while doubling up on the mid-bass unit gives
it greater power handling, ideal for the extra level the centre channel
often needs to achieve. Secondly the Reveal X is ideally suited to re-mix
monitoring for DJs. Stereo re-mix monitoring requires the same standard of
accuracy as any other music recording, and many DJs use Reveals for this
reason. Now you can have the same quality with the Reveal X and benefit
from increased sound pressure levels, which really convey the emotion of
dance music.
PERFORMANCE
| Sensitivity
(half space) |
90 dB / 2.83
V @ 1 m |
| Nominal
Impedance |
8 ohms |
| Frequency
Response ± 3 dB |
65 Hz - 20
kHz |
| Power
Handling (RMS/Programme) |
75 / 150
Watts |
| Recommended
Amplifier Power |
60 to 150
Watts into 8 ohms |
DRIVE UNITS
| High
Frequency |
1" soft
dome tweeter, shielded |
| Low
Frequency |
2 x
6.5" bass driver, shielded |
| Dispersion |
120° |
CROSSOVER
CONSTRUCTION
| Enclosure
Type |
optimized
bass-reflex loaded |
| Volume |
19 Litres |
| Dimensions |
8.30"
x 20.80" x 10.25" |
| Weight |
29.3 lbs |
| Finish |
Red satin
baffle
Grey suedette vinyl sides and back |
| Front
Baffle Panel |
1
1/4" MDF |
| Magnetically
Shielded |
Included |
|
 |
|
|
|
