Dimensions
- Width: 19 in / 48.26 cm
- Height 3.5 in / 8.89 cm
- Depth: 15.19 in / 38.58 cm
- Weight: 17.58 lbs / 7.97 kg
A/D
- Sample Rate: 44.1, 48, 88.2, 96
kHz ±10%
- Dynamic Range: 115 dB (A-weighted),
112 dB (unweighted); see Notes 1 and 4
- THD+N: 0.0007% (–103 dB); +17
dBu @ 997 Hz; see Note 1
- Frequency Response: ±0.05 dB @
–2 dBu, 20 Hz – 20 kHz; see Notes 1 and 2
D/A
- Sample Rate: 44.1, 48, 88.2, 96
kHz ±10%
- Dynamic Range: 114 dB (A-weighted),
112 dB (unweighted); see Notes 1 and 3
- THD+N: 0.0013% (–97 dB); –1
dBFS @ 997 Hz; see Note 1
- Frequency Response: +0.1/–0.2
dB; –20 dBFS, 20 Hz – 20 kHz; see Notes 1 and 2
- Sample Rate = 48 kHz, Noise BW =
22 Hz – 20 kHz unless otherwise noted,
Tambient = +25 C
Note 1:
Measurement made using +4 dBu inputs or outputs
Note 2: Measured relative to level at 1 kHz
Note 3: Measured with digital input at –60 dBFS @ 997 Hz
Note 4: ADC measured with analog input level at –42 dBu @ 997 Hz
|
