Specifications
Video
Format:
|
NTSC
or PAL
|
Display
Format:
|
1,
4, 6, 7, 8, 9 Multiscreen, PiP, 2x Digital Zoom (Live
& Playback Mode), Duplex Mode
|
Video
Inputs:
|
9
Camera Inputs with
Loop
Through, Automatic Vp-p 75 Ohm Termination
|
Video
Output:
|
9
Loop
-through Video Output, 1 Vp-p at 75 Ohm, 1
Main Monitor Output, 1 Vp-p at 75 Ohm, 1 S-Video
Output Mini DIN, for Main Monitor 1 Call Monitor
Output, 1 Vp-p at 75 Ohm 4 Matrix Monitor Outputs, 1
Vp-p at 75 Ohm
|
Video
Compression:
|
6
Step M-JPEG
|
Record
Resolution:
|
720
x 484 (NTSC) ; 720 x 576 (PAL)
|
Compact
Flash Memory:
|
Yes,
Built-In Compact Flash Card Slot
|
Alarm
Input:
|
9
Alarm Inputs, 1 Alarm Reset Input
|
Alarm
Output:
|
1
Alarm Relay Output
|
Video
Display:
|
Full,
PiP, Quad, & 2x2 Zoom for Live & Playback
|
Audio:
|
2
Mono Inputs; 2 Mono Outputs
|
Video
Pause:
|
Yes
|
Video
Loss Detection:
|
Yes
|
Control:
|
Front
Panel, IR Remote, RS-232,
|
Event
Log:
|
Yes
|
Hard
Disk Storage:
|
2
x 3.5’’ IDE Hot Swappable Hard Drive
|
Recording
Mode:
|
Continuous
time-lapse recording, Timer or Alarm and Motion
Recording
|
Recording
Rate:
|
0.2~60
IPS (NTSC); 0.1~50 IPS (PAL)
|
Playback
Rate:
|
0.2~60
IPS (NTSC); 0.1~50 IPS (PAL)
|
Playback
Search:
|
By
Date/Time, Event, or Segment
|
Motion
Detection:
|
14
x 10 Grids per Camera with Adjustable Sensitivity
|
Setup:
|
On-Screen
Display
|
User
Interface:
|
Menu
Driven
|
User
Input Device:
|
Front
Panel Keypad
|
Timer:
|
Max
12 Different Timer Periods
|
Title:
|
12
Character Title Generator For Each Camera
|
Ethernet:
|
RJ45,
10 MB Interface
|
Watch
Dog Timer:
|
Yes
|
Password
Protection:
|
For
Menu and Recording
|
Power
Source:
|
24V
AC + 10%, Max AC 1.5 Amp
|
Power
Consumption:
|
60
W max
|
Operating
Temperature:
|
0°C
~ +40°C
|
Dimensions:
|
430
(L) mm x 88 (W) mm x 300 (H) mm
|
Weight:
|
4.85
Kg
|
Features
- Digital
recording provides superior quality images
- 2 x 3.5"
IDE "Hot Swap" hard disk
- Pre-alarm
image recording
- Time-lapse and real time recording
- Programmed with various time-lapse speeds
- Real-time live display for all cameras
- Variable recording speeds up to 60 IPS
- Alarm-activated recording
- Audio recording capability
- Easy-to-use jog/shuttle control panel with common VCR
functions
- Instant retrieval of stored video
- On-screen setup menu and system timer
- Built-in M-JPEG compression with configurable quality
- Real-time
live display
- Full,
4, 6, 7, 8, 9, PiP and 2x digital zoom display in live and
playback mode, duplex mode
- Operation
via front panel, IR remote control, network or RS-485
keyboards KS KBJ and KS KBK
- 2
main monitor, 1 call monitor and 4 matrix monitor outputs
- Ethernet
TCP/IP connectivitiy for remote viewing and controlling
- Pre-
and post-alarm recording
- Export
of recorded images or videostreams via CompactFlash or network
- Audio
recording capability
- Continuous,
timer, alarm and motion recording
- The
Jog & Shuttle function allows up to 600x playback and
reverse playback without any image interferences
|
