Video Format:

NTSC or PAL

Display Format:

1, 4, 6, 7, 8, 9x Multiscreen 16 million colors

Video Inputs:

9 Camera Inputs, 1 Vp-p/75 Ohm

Video Output:

9 Loop -through Video Output, 1 Vp-p at 75 Ohm, 1 BNC Composite Video Output, 1 Vp-p/75 Ohm, 1 mini-din S-Video output, 1 Vp-p/75 Ohm, 1 call BNC Composite Output, 1 Vp-p/75 Ohm

Video Compression:

MPEG-4

Display Resolution:

720 x 484 for NTSC, 720 x 576 for PAL

Alarm Input:

9 Alarm Inputs, Normally Open or

Normally Closed Programmable

Alarm Output:

4 Alarm Relay Outputs

Audio:

4 3.5 mm Mono Input; 4 3.5 mm Mono Output

Video Pause:

Yes

Video Loss Detection:

Yes

Event Log:

Yes

Hard Disk Storage:

2 HOT Swap x 3.5’’ IDE Hard Drive and SCSI External Controller

Recording Mode:

Continuous time-lapse recording, Timer or Alarm and Motion Recording

Recording Rate:

Up to 120 IPS (NTSC) per camera

Playback Rate:

Up to 120/100 pictures per second

Playback Search:

By Date/Time or Event

Motion Detection:

Yes, with configurable grids per Camera with Adjustable Sensitivity

Setup:

On-Screen Display

User Interface:

Menu Driven

User Input Device:

Front Key Panel

Title:

12 Character Title Generator For Each Camera

Ethernet:

RJ45 network connector

Password Protection:

For Menu and Recording

Power Source:

24V AC + 10%

Power Consumption:

60 W max

Operating Temperature:

0°C ~ +40°C

Dimensions:

430 (L) mm x 88 (W) mm x 300 (H) mm
