Video
Format:
|
NTSC
or PAL
|
|
Display
Format:
|
1,
4, 7, 9x Multiscreen 16 million colors
|
|
Video
Inputs:
|
8
Camera Inputs, 1 Vp-p/75 Ohm
|
|
Video
Output:
|
8
Loop
-through Video Output, 1 Vp-p at 75 Ohm, 1 BNC Composite
Video Output, 1 Vp-p/75 Ohm, 1 mini-din S-Video output,
1 Vp-p/75 Ohm, 1 D-Sub 15 pin computer monitor output, 1
call BNC Composite Output, 1 Vp-p/75 Ohm
|
|
Video
Compression:
|
MPEG-4
|
|
Display
Resolution:
|
640
x 480 for NTSC, 800 x 600 for PAL
|
|
Alarm
Input:
|
8
Alarm Inputs, Normally Open or Normally
Closed Programmable
|
|
Alarm
Output:
|
8
Alarm Relay Outputs; 4 Normally Open, 4 Normally Closed
|
|
Audio:
|
1
3.5 mm Mono Input; 1 3.5 mm Mono Output
|
|
Video
Pause:
|
Yes
|
|
Video
Loss Detection:
|
Yes
|
|
Control:
|
On-Screen
User Interface, Mouse-controlled (keyboard optional)
|
|
Event
Log:
|
Yes
|
|
Hard
Disk Storage:
|
2
x 3.5’’ IDE Hard Drive, one non-removable, one hot
swappable
|
|
Storage
Media for Export:
|
1
Set of IDE Type CD/RW or DVD/RW
|
|
Recording
Mode:
|
Continuous
time-lapse recording, Timer
or Alarm and Motion Recording
|
|
Recording
Rate:
|
Up
to 30 FPS (NTSC) or 25 FPS (PAL) per camera
|
|
Playback
Rate:
|
Up
to 30 FPS (NTSC) or 25 FPS (PAL) per camera
|
|
Playback
Search:
|
By
Date/Time, Event, or Location
|
|
Motion
Detection:
|
16
x 12 Grids per Camera with Adjustable Sensitivity
|
|
Setup:
|
On-Screen
Display
|
|
User
Interface:
|
Menu
Driven
|
|
User
Input Device:
|
Front
Key Panel or Remote
|
|
Title:
|
10
Character Title Generator For Each Camera
|
|
Ethernet:
|
RJ45,
10/100 MB Interface
|
|
Password
Protection:
|
For
Menu and Recording
|
|
Power
Source:
|
24V
AC + 10%, Max AC 2.6 Amp
|
|
Power
Consumption:
|
150
W max
|
|
Operating
Temperature:
|
0°C
~ +40°C
|
|
Dimensions:
|
430
(W) mm x 360 (D) mm x 110 (H) mm
|
