HDSTORM, EDIUS
NX Express and EDIUS
SP-SDI are NLE Systems built around EDIUS editing software. All three
packages include a copy of EDIUS, in addition to the hardware that
characterizes each. EDIUS software also directly supports OHCI FireWire,
providing video input/output from DV and HDV devices.
- Edit any mix of SD and HD resolution
video content together in real time
- Work with many different native video
formats, including DV, HDV, AVCHD, uncompressed, and more
- New GPU-accelerated 3D transitions
- Fast, flexible user interface, including
unlimited video, audio, title, and graphics tracks
- Real-time editing and conversion of
different HD/SD aspect ratios, such as 16:9 and 4:3
- Real-time editing and conversion of
different frame rates, such as 60i, 50i, and 24p
- Real-time editing and conversion of
different resolutions, such as 1920x1080, 1440x1080, 1280x720, and
720x480
- Real-time HD/SD effects, keyers,
transitions, and titles
- Supports newer file-based formats,
including Infinity JPEG 2000, XDCAM and XDCAM EX, P2 (DVCPRO and
AVC-Intra), and GFCAM
- Real-time, render-free DV output
directly from the timeline
- Multi-camera editing of up to eight
different sources simultaneously
- Nested timeline sequences
- High-speed SD and HDV MPEG-2 timeline
export, built for dual-core CPU technology
- High-quality, multi-format video
exporting to Infinity JPEG 2000, MPEG-2, AVCHD, AVC-Intra, and more
- Direct-to-DVD timeline export
- High value software bundle includes
filters, effects, image stabilization, titling, VST audio plug-ins,
and DVD and Blu-ray authoring
- Compatible with Windows® XP and Windows
Vista
- EDIUS v5 software installation disc set
(DVD-ROM)
- EDIUS USB dongle
- EDIUS QuickStart guide
- NewBlue video filters: Art Effects, Film
Effects and Motion Effects
- ProDAD video effects and image
stabilization: VitaScene and Mercalli Expert
- iZotope VST audio plug-ins: Audio
Effects Suite, AudioRestore, AGC and Mastering Effects Suite
- Corel DVD and Blu-ray authoring: DVD
MovieFactory
- Inscriber titling: TitleMotion Pro for
EDIUS
- Artbeats SD and HD stock footage and
graphics
- 1920 x 1080/59.94i, 50i, 29.97p, 25p,
24p, 23.98p
- 1440 x 1080/59.94i, 50i, 29.97p, 25p,
25p over 50i, 24p, 23.98p
- 1280 x 1080/59.94i, 29.97p over 59.94i,
23.98 over 59.94i, 23.98pA over 59.94i
- 1280 x 720/59.94p, 50p, 29.97p, 25p,
23.98p
- 960 x 720/59.94p, 50p, 50p over 60p,
29.97p over 59.94p, 25p over 50p, 25p over 60p, 24p over 60p, 23.98p
over 59.94p
- 720 x 576/50p 4:3, 50p 16:9, 50i 4:3,
50i 16:9, 25p 16:9, 25p over 50i 4:3, 25p over 50i 16:9
- 720 x 486/59.94i 4:3, 59.94i 16:9
- 720 x 480/59.94p 16:9, 59.94i 4:3,
59.94i 16:9, 29.97p over 59.94i 4:3, 29.97p over 59.94i 16:9, 23.98p
over 59.94i 4:3, 23.98p over 59.94i 16:9, 23.98pA over 59.94i 4:3,
23.98pA over 59.94i 16:9
- Canopus DV
- Canopus HQ
- Canopus Lossless
- Infinity JPEG 2000
- 3GPP
- AVCHD
- AVC-Intra
- DirectShow video*
- DV25
- DVCPRO 50 (including P2)
- DVCPRO HD (including VariCam, P2)
- GFCAM
- H.246 TS*
- MPEG-1 (system or elementary** stream)
- MPEG-2 (program or elementary** stream)
- MPEG-2 (HDV)
- MXF*
- QuickTime*
- Uncompressed (AVI)
- XDCAM (SD and HD)
- XDCAM EX
- Windows Media Video
- DPX(SMPTE 268M-2003)
- Flash Pix File
- GIF
- JPEG
- JPEG File Interchange Format
- Mac Pict File
- Maya IFF File
- Photoshop
- Portable Network Graphics (PNG)
- QuickTime Image File
- SGI
- Targa
- Windows Bitmap
- Windows Meta File
- AAC
- AIFF
- Dolby Digital AC-3
- MPEG audio
- MPEG audio layer-3 (MP3)
- Ogg Vorbis
- PCM Wave
- Windows Media Audio
EDIUS editing software is capable of editing both SD and HD content in
real time, however the system requirements for real-time HD editing are
significantly higher than for SD editing. The requirements shown here are
for real-time HD editing.
- Intel or AMD CPU with a 3 GHz processor
speed or faster (multiple CPUs and/or multi-core CPUs are recommended.
SSE2 and SSE3 instruction set supported)
- 1 GB RAM (2 GB or more recommended)
- 800 MB free disk space
- DVD-ROM drive for software installation
- ATA100/7200 rpm or faster hard disk,
capable of sustaining at least 20 MB/sec data transfer. A RAID stripe
set of two or more hard disk drives is required for multiple HD stream
output
- Graphics card with at least 256 MB of
graphics memory (512 MB recommended) with support for PixelShader
Model 3.0 or later(i.e. DX9-based)
- One free 5.25-inch mounting bay (required
if using the HDSTORM Bay)
- Windows® XP Home or Windows® XP
Professional (32-bit, Service Pack 2 or later), or Windows Vista
(32-bit or 64-bit, Service Pack 1 or later)
- One free USB (1.1 or higher) port for
security key
- Soundcard
- IEEE 1394 FireWire
- ACEDVio
- HDSTORM**
- EDIUS NX series
- EDIUS SP series
- EDIUS SD/HDLE/HD series
|
